MÖRTEL MEİSTER FCP20 FOAM GENERATOR

MÖRTEL MEİSTER FCP20 FOAM GENERATOR

Mörtel Meister FCP 20 comes on stage as a fine-tuned performant foam concrete producing unit to answer the growing use and need for on-site batching and pumping of foam concrete. With its built-in fully controlled foam generator, simple and adequate concept, optimum producing capacity and performance, FCP 20 emphasizes work and environment safety.

Category: Light Concrete Machine

Mixer Engine

:

5,5 KW

Pump  Engine

:

7,5 KW

Compressor  Engine

:

5,5 KW

Spiral Type

:

KEH800

Water Pump Engine

:

2,2 KW

Dimensions L/W/H

:

3780 / 1735 / 1800 mm

Standard Weight

:

1420 kg.

Transfer Range

:

Max. 50. mt Vertical 100 mt. Horizontal

Loading Height

:

1300 mm

Pump Capacity

:

440 Lt / dk. (min)

Vessel Capacity



1 m3

Foam Generator Capacity

:

510 Lt / dk. (min)

Water Tank Capacity



200 Lt

Air Tank Capacity

:

50 Lt

Drawbar and Axle

:

Adjustable Drawbar and Braked Axle

√ Interior Spray Foam Insulation

√ Exterior Spray Foam Insulation

√ Floor Foam Insulation
