Engine |
: |
Deutz D2011 Diesel Engine 36,6 KW/46 KW |
|
Manuel Flow Rate |
: |
Min. 4m3/h - Max. 20m3/hс |
|
Max. Theoretical Pressure of the Concrete |
: |
71,1 bar |
|
Diameter of the Transfering Cylinder |
: |
150 mm |
|
The Pressure of the Piston |
: |
800 mm |
|
Valve System of the Concrete |
: |
S-Valve |
|
Max. Pressure of the Hydraulic |
: |
250 bar |
|
Max. Aggregates Size |
: |
32 mm |
|
Hydraulic Tank Capacity |
: |
150 Litres |
|
Fuel Tank |
: |
55 Litres |
|
Concrete Discharge Diameter |
: |
125 mm |
|
Tank Volume |
: |
320 Litres |
|
Dimension L/W/H |
: |
4600 / 1700 / 1500 mm |
|
Total Weight |
: |
2300 Kg |
|
Drawbar and Axle |
: |
Adjustable Drawbar and Braked Axle |
